quality Transparent High Transmittance Quartz Glass Tube with Good Electrical Insulation and Corrosion Resistance factory

Transparent High Transmittance Quartz Glass Tube with Good Electrical Insulation and Corrosion Resistance

Name: Transparent High Transmittance Quartz Glass Tube with Good Electrical Insulation and Corrosion Resistance
Brand: Lianyungang Shengfan Quartz Product Co., Ltd
SKU: SF221012001
Price: 4.50 USD
Availability: InStock

Brand Name: shengfan

Model Number: SF221012001

Place of Origin: China

Certification: ISO9001

Minimum Order Quantity: Negotiable

Price: Negotiable

Supply Ability: 100,000 pieces per month

fused silica tubing

fused quartz tube

glass test tubes

Product Details

Name:	High Transmittance Polished Quartz Glass Fire Pipe Semiconductor Protect Heat Resistant Vacuum Tube Transparent	Application:	Sources , Semiconductor
Material:	SIO2>99.99%	Feature:	Good Electrical Insulation
Light Transmittance:	>92%	Working Temparature:	1100℃
Hardness:	Mose 6.5	Resistance Value:	1000 Times Than Ordinary Glass
Color:	Transparent
Highlight	Heat Resistant Quartz Glass Tube , Polished Quartz Glass Tube , Quartz Glass Vacuum Tube

Product Description

Transparent Heating Quartz Glass Tube High Transmittance Polished

Transparent High Transmittance Quartz Glass Tube with Good Electrical Insulation and Corrosion Resistance 0

Factory price Transparent Heating Quartz Glass Tube

High quality electrical insulation quartz glass tube for light sources and semiconductor applications.

Main Applications

Lighting, light sources, semiconductor, optical communications, military, building materials, chemical processing, mechanical engineering, electrical components, environmental protection and various industrial fields.

Material Properties

High Durability
High Heat Resistance
High Corrosion Resistance
Low Thermal Expansion Coefficient

Corrosion Resistant

Except for hydrofluoric acid, quartz glass exhibits no chemical reaction with other acids. Its acid resistance is 30 times that of ceramic and 150 times that of stainless steel. The chemical stability at low temperatures is unmatched by any other engineering materials.

Excellent Thermal Stability

The low thermal expansion coefficient of quartz glass enables it to withstand severe temperature changes. Quartz glass heated to 1100℃ will not crack when immersed in cold water.

Superior Light Transmission

Quartz glass provides excellent transmittance across all spectral bands from ultraviolet to infrared. Visible light transmittance exceeds 93%, with maximum transmittance over 80% in the ultraviolet spectral region.

Outstanding Electrical Insulation

The electrical resistance of quartz glass is 10,000 times that of ordinary glass, maintaining excellent electrical performance even at low temperatures.

Applications of Standard Clear Quartz Tube

Halogen lamps, mercury lamps, single-end lamps, automobile lamps, stage lighting, thermoelectric boilers, photocopier lamps, water treatment lamp casings, quartz ware and piping systems.

Shengfan Quartz Plate Characteristics

SiO₂ Content	99.9%
Density	2.2 g/cm³
Mohs Hardness	6.6
Melting Point	1732℃
Working Temperature	1100℃
Maximum Short-term Temperature	1450℃
Visible Light Transmittance	Above 93%
UV Spectral Region Transmittance	80%
Annealing Point	1180℃
Softening Point	1630℃
Strain Point	1100℃

Transparent High Transmittance Quartz Glass Tube with Good Electrical Insulation and Corrosion Resistance 1

Transparent High Transmittance Quartz Glass Tube with Good Electrical Insulation and Corrosion Resistance 2

Transparent High Transmittance Quartz Glass Tube with Good Electrical Insulation and Corrosion Resistance 3

Transparent High Transmittance Quartz Glass Tube with Good Electrical Insulation and Corrosion Resistance 4

Transparent High Transmittance Quartz Glass Tube with Good Electrical Insulation and Corrosion Resistance 5

Transparent High Transmittance Quartz Glass Tube with Good Electrical Insulation and Corrosion Resistance 6

Transparent High Transmittance Quartz Glass Tube with Good Electrical Insulation and Corrosion Resistance 7

Company Profile

Lianyungang Shengfan Quartz Product Factory is a professional manufacturer specializing in research, development and production of quartz plates, quartz tubes, quartz flanges, quartz rings, cuvettes and quartz instruments. Located in China's Crystal Capital - Donghai City, Jiangsu Province, our facility is 70 km from Lianyungang port with convenient transportation access.

Covering 1,000 square meters with over 30 employees, we achieve annual sales exceeding USD 5.2 million. Guided by our philosophy of Technology Orientation, Quality First, Integrity and Responsibility, and Sustainable Operation, we are committed to establishing an international enterprise with standardized and sustainable operational capabilities.

Transparent High Transmittance Quartz Glass Tube with Good Electrical Insulation and Corrosion Resistance 8

LIANYUNGANG SHENGFAN QUARTZ PRODUCTS CO. LTD

Mobile/WhatsApp: +8617696882108

E-mail: shengfanquartz@163.com, my@quartzglassproducts.com

Address: Economic Development Zone, Donghai County, Lianyungang City, Jiangsu Province, China

Transparent High Transmittance Quartz Glass Tube with Good Electrical Insulation and Corrosion Resistance 9

Transparent High Transmittance Quartz Glass Tube with Good Electrical Insulation and Corrosion Resistance 10

Product Highlights

Transparent Heating Quartz Glass Tube High Transmittance Polished Factory price Transparent Heating Quartz Glass Tube High quality electrical insulation quartz glass tube for light sources and semiconductor applications. Main Applications Lighting, light sources, semiconductor, optical communication...
