Customized Lager Transparent Quartz Glass Substrates Quartz Glass Plate

Place of Origin CHINA
Brand Name SF
Certification ISO9001
Model Number QGP-4
Minimum Order Quantity 10 pieces
Price Negotiable
Packaging Details plastic bubble/ polystyrene foam sheet/ carton/ wooden pallet
Delivery Time 5-30 work days
Payment Terms L/C, T/T
Supply Ability 10,000 pieces per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Quartz Name Quartz Glass Plate Material 99.99%
Light Transmittance 92% Density 2.2g/cm3
Working Temparature 1100℃ Hardness Morse 6.5
Melt Point 1750-1850℃
Highlight

fused quartz glass sheet

,

2.2g/cm3 fused quartz sheet

,

2.2g/cm3 Quartz Glass Sheet

Leave a Message
Product Description

Quartz plate:

1.Translucence Quartz Glass thickness 0.3-30mm, OD: 1-500mm.
2.Thickness Tolerance: +/-0.1mm
3.Raw Material: Quartz , SiO2: >=99.99%
4.Color : Clear , Translucence.
5.Surface quality :40/20 60/40
6.Transmittance >90%
7.Sharpe: Square , Circle, Can make the size and shape according to customer's require.

Support customization:
Their size can designed according your need and can be grinded and polishing the sides according your need!
Product Details
1. SiO2> 99.99% ,high purity quartz tube.
2.Operating Temperature: 1250℃ SoftenTemperature: 1730℃.
3.Excellent visual and chemical performance .
4. without surface coating and infectant.
5. Health care and environmental protection.
6. Any dimension can be made.
7. CE.RoHs SGS approved.
Quartz Characteristic
*Brand shengfanquartz
*SIO2 99.99%
*Density 2.2(g/cm³)
*Degree of hardness moh’ scale 6.6
*Melting point 1732℃
* Working temperature 1100℃
*Annealing point 1180℃
*Softening point 1630℃


Setting Information

Color Transparent
Shape Circular / Round
Standard JGS1,JGS2,JGS3
Material 99.99% sio2
Diameter 1-800mm
Application Optics quartz windows
Light Transmittance >92%



Tolerance ±0.01 ±0.05mm ±0.1mm
Surface treatment 60/40 40/20
Shape square and circle custom shape any shape can be customed
Application case Remote control window vacuum cup
germicidal lamp



Customized Lager Transparent Quartz Glass Substrates Quartz Glass Plate 0



Details Images

Customized Lager Transparent Quartz Glass Substrates Quartz Glass Plate 1

Customized Lager Transparent Quartz Glass Substrates Quartz Glass Plate 2Customized Lager Transparent Quartz Glass Substrates Quartz Glass Plate 3



Packing & Delivery

Customized Lager Transparent Quartz Glass Substrates Quartz Glass Plate 4



Company profile:

Lianyungang Shengfan Quartz Product Factory is a professional manufacture specialized in research and development of quartz plate,quartz tube,quartz flange,quartz ring,cuvette and quartz instrument. The company is located in China Crystal Capital - Donghai City, Jiangsu Prov., China. 70 km far from Lianyungang port, convenient transportation.
Covering an area of 1000 square meters,we now have over 30 employees,an annual sales figure exceeding USD 5.2 million.
With the philosophy of Technology Orientation, Quality First,Integrity and Responsibility,Sustainable Operation, the company dedicates to establish an international enterprise with standard and sustainable operation capability.

Customized Lager Transparent Quartz Glass Substrates Quartz Glass Plate 5

LIANGYUNGANG SHENGFAN QUARTZ PRODUCTS CO., LTD
TEL : 00860518878938285
Mobile : 008619901512909
Wechat : shengfanquartz
E-mail : shengfanquartz@163.com
Website : https://shengfanquartz.1688.com
Address : NO.169 Mingzhu Rd, Economic Development Zone, Donghai country,Lianyungang city, Jiangsu prov.,China.



FAQ:

Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the delivery time?
A:Within 15 days after receiving deposit.
Q3. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available
Q4. How to proceed an order in your factory?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q5. How do you ship the goods and how long does it take to arrive?
DHL, UPS, FedEx or TNT are optional for small order. It usually takes 3-5 days to arrive.
Airline and sea shipping are also available.
