Clear Quartz Glass Plate Heat Resistant Customized 99.99% Pure Flat Glass Plate
Product description:
Fused clear silica quartz glass plate is made of high purity quartz sand with excellent thermal shock stability and high transmittance. It is widely used in electric light/ laser/ lenses/optical instrument/high temperature window.
Product Details:
1.SiO2> 99.99% ,high purity quartz tube.
2.Operating Temperature: 1250℃ SoftenTemperature: 1730℃.
3.Excellent visual and chemical performance .
4.Without surface coating and infectant.
5.Health care and environmental protection.
6.Any dimension can be made.
7.CE.RoHs SGS approved.
Product Parameters
Property | Typical Values | Property | Typical Values |
Density | 2.2x103 kg/m3 | Electrical Resistivity | 7x107 ohm cm (350°C) |
Hardness | 5.5 - 6.5 Mohs' Scale | Index of Refraction | 1.4585 |
Design Tensile Strength | 4.8x107 Pa (N/m2) | Strength | 5x107 V/m |
Bulk Modulus | 3.7x1010 Pa (5.3x106) | transmittance rate | 85% |
Rigidity Modulus | 3.1x1010 Pa (4.5x106) | Sonic Attenuation | Less than 11 db/m |
Softening Point | 1683°C | Helium | 210x10-10 |
Annealing Point | 1215°C | Hydrogen | 21x10-10 |
Strain Point | 1120 °C | Deuterium | 17x10-10 |
Brand Name | ShengFan |
Thickness | 0.5-100mm |
Place of Origin | jiangsu.China |
Density | 2.2g/cm3 |
Material | SIO2>99.99% |
Hardness | Morse 6.5 |
Size | Customized |
Annealing point | 1180℃ |
Strain point | 1100℃ |
Model Number | QSP-1 |
Raw material
Company profile:
Lianyungang Shengfan Quartz Product Factory is a professional manufacture specialized in research and development of quartz plate,quartz tube,quartz flange,quartz ring,cuvette and quartz instrument. The company is located in China Crystal Capital - Donghai City, Jiangsu Prov., China. With the philosophy of Technology Orientation, Quality First,Integrity and Responsibility,Sustainable Operation, the company dedicates to establish an international enterprise with standard and sustainable operation capability.
LIANGYUNGANG SHENGFAN QUARTZ PRODUCTS CO. LTD
TEL : 00860518878938285
Mobile : 008619901512909
Wechat : shengfanquartz
E-mail : shengfanquartz@163.com
Website : https://shengfanquartz.1688.com
Address : NO.169 Mingzhu Rd, Economic Development Zone, Donghai country,Lianyungang city, Jiangsu prov.,China.
FAQ:
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the delivery time?
A:Within 15 days after receiving deposit.
Q3. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available
Q4. How to proceed an order in your factory?
A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.
Q5. How do you ship the goods and how long does it take to arrive?
A:DHL, UPS, FedEx or TNT are optional for small order. It usually takes 3-5 days to arrive. Airline and sea shipping are also available.
