| Shengfan Quartz plate characteristic |
| *Brand |
shengfanquartz |
| *SIO2 |
99.99% |
| *Density |
2.2(g/cm³) |
| *Degree of hardness moh’ scale |
6.6 |
| *Melting point |
1732℃ |
| * Working temperature |
1100℃ |
| *Annealing point |
1180℃ |
| *Softening point |
1630℃ |
1.Square piece regular four kinds of corner
2.Shaped quartz plates are producedby providing samples or drawings
Unit: mm
Remarks:In addition there are requirements such as tolerance, polish, translucency, etc. can beprovided according to demand.
We can customize any size quartz glass plate according to your drawing.
【Application scope】:Used to make semiconductors, electric light source device, semi-conductor communication devices, lasers,
optical instruments, laboratory instruments, electrical equipment, medical equipment and chemical instruments, chemical industry,
electronics, metallurgy and other industries.
【Product advantages】: not easy to be corroded, can withstand high temperature, beautiful appearance, compact structure, easy to operate, strong light transmission, good electrical insulation.
| |
JGS1(ZS-1) |
JGS2(ZS-2) |
JGS3(HS) |
| Spectral characteristics |
180-2500nm |
200-2500nm |
260-3500nm |
| The average transmittance |
90% |
85% |
85% |
| Bubble class |
0 |
2 |
2 |
| Birefringence |
1-2 |
1-2 |
1-2 |
| Grain structure |
1 |
2 |
2 |
| Fringe |
1-2 |
2 |
2 |
| Uniformity |
1-2 |
2 |
2 |
| Uniformity |
1 |
2 |
2 |
| Radiation Performance |
Does not change clolor |
Sight discoloration |
Change color |
Details Images
Production process
Certificate
Product use
Packing & Delivery
Company Introduction
Lianyungang Shengfan Quartz Product Factory is a professional manufacture specialized in research and development of quartz plate,quartz tube,quartz flange,quartz ring,cuvette and quartz instrument. The company is located in China Crystal Capital - Donghai City, Jiangsu Prov., China. 70 km far from Lianyungang port, convenient transportation.
Covering an area of 1000 square meters,we now have over 30 employees,an annual sales figure exceeding USD 5.2 million.
With the philosophy of Technology Orientation, Quality First,Integrity and Responsibility,Sustainable Operation, the company dedicates to establish an international enterprise with standard and sustainable operation capability.
Our Services & Strength
The company adhere to the integrity of business, experience, reasonable price, quality assurance, to provide excellent after-sales service, we sincerely welcome customers to come to negotiate
FAQ
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the delivery time?
A:Within 15 days after receiving deposit.
Q3. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available
Q4. How to proceed an order in your factory?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q5. How do you ship the goods and how long does it take to arrive?
DHL, UPS, FedEx or TNT are optional for small order. It usually takes 3-5 days to arrive.
Airline and sea shipping are also available.
