High Temperature Quartz Glass Plate Flat Sheet Sight Window 100mm
Product Details
| Type: | Clear Quartz Plate | Application: | Semiconductor, Optical |
|---|---|---|---|
| Thickness: | 0.5-100mm | Shape: | Square |
| Processing Service: | Bending, Welding, Punching, Cutting, Polishing | Product Name: | Quartz Plate |
| Material: | SIO2>99.99% | Surface Quality: | 60/40 |
| Density: | 2.2g/cm3 | Working Temparature: | 1150℃ |
| Hardness: | Morse 6.5 | Melt Point: | 1750-1850℃ |
| Acid Tolerance: | 30 Times Than Ceramics,150 Times Than Stainless Steel | Size: | Customized |
| Annealing Point: | 1180℃ | Port: | Shanghai And Qindao Port |
| Highlight |
high temperature Quartz flat Glass Plate,100mm Quartz Glass Plate Sheet,Customized Quartz Glass Plate Sheet |
||
Product Description
|
Shengfan Quartz plate characteristic
|
|
|
|
*Brand
|
shengfanquartz |
|
|
*SIO2
|
99.99%
|
|
|
*Density
|
2.2(g/cm³)
|
|
|
*Degree of hardness moh’ scale
|
6.6
|
|
|
*Melting point
|
1732℃
|
|
|
* Working temperature
|
1100℃
|
|
|
*Annealing point
|
1180℃
|
|
|
*Softening point
|
1630℃
|
|
1. Translucence Quartz Glass thickness 0.3-30mm, OD: 1-500mm
2. Thickness Tolerance: +/-0.1mm
3. Raw Material: Quartz , SiO2: >=99.99%
4. Color : Clear , Translucence.
5. Surface quality :40/20 60/40
6. Transmittance >90%
7.S harpe: Square , Circle, Can make the size and shape according to customer's require.
|
Tolerance
|
±0.01
|
±0.05mm
|
±0.1mm
|
|
Surface treatment
|
60/40
|
40/20
|
|
|
Shape
|
square amd circle
|
custom shape
|
any shape can be customed
|
|
Application case
|
Remote control window
|
vacuum cup
|
germicidal lamp
|
