Anti Corrosion Fused Quartz Urn 2.2g/Cm3 Chemical Reaction

Place of Origin China
Brand Name SF
Certification TS16949
Model Number QC-1
Minimum Order Quantity 5 pieces
Price Negotiable
Packaging Details plastic bubble/ polystyrene foam sheet/ carton/ wooden pallet
Supply Ability 1000 pieces

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material SIO2>99.99% Density 2.2g/cm3
Hardness Morse 6.5 Melt Point 1750-1850℃
Working Temperature 1110℃ Application Chemical Reaction
High Light

Fused Quartz Urn 2.2g/cm3

,

Chemical Reaction Fused Quartz Urn

,

Anti Corrosion Fused Quartz Urn

Leave a Message
Product Description



Quartz Cylinder High Temperature Clear Fused Quartz Urn For Jewelry Display



Product description:



1. Purity:


SiO2 content is more than 99.9%, transparent quartz glass tube can reaches above 99.95%.


2. Temperature :


Softening point temperature is about 1730 degrees Celsius ,1150 degrees Celsius in a long time used ,short-time maximum use temperature is up to 1450 degrees Celsius.


3. Anti-corrosion:


Quartz glass is acidic materials, except hydro fluoric acid and 300 degrees Celsius thermal phosphoric acid, on any other acids were shown to be inert, is the best anti acid materials.

Shengfan Quartz plate characteristic
SIO2 99.9%
Density 2.2(g/cm³)
Degree of hardness moh’ scale 6.6
Melting point 1732℃
Working temperature 1100℃
Max temperature can reach in a short time 1450℃
Visible light transmittance Above 93%
UV spectral region transmittance 80%
Annealing point 1180℃
Softening point 1630℃
Strain point 1100℃



  JGS1(ZS-1) JGS2(ZS-2) JGS3(HS)
Spectral characteristics 180-2500nm 200-2500nm 260-3500nm
The average transmittance 90% 85% 85%
Bubble class 0 2 2
Birefringence 1-2 1-2 1-2
Grain structure 1 2 2
Fringe 1-2 2 2
Uniformity 1-2 2 2
Fluorescence 1 2 2
Radiation Performance Does not change clolor Sight discoloration Change color

The advantages of Customized High Quality Clear Quartz Glass Flask are:


1. low thermal conductivity,
2. small expansion coefficient,
3. high temperature proof,
4. excellent thermo stability and cost lower than other quartz glass.
5. It has been widely used as long nozzle and immersion nozzle brick for the continuously flood steel,



Application of quartz labware



Chemical experiment, Reaction apparatus, Oven haetinAnti Corrosion Fused Quartz Urn 2.2g/Cm3 Chemical Reaction 0

Anti Corrosion Fused Quartz Urn 2.2g/Cm3 Chemical Reaction 1Anti Corrosion Fused Quartz Urn 2.2g/Cm3 Chemical Reaction 2


Company profile:



Lianyungang Shengfan Quartz Product Factory is a professional manufacture specialized in research and development of quartz plate,quartz tube,quartz flange,quartz ring,cuvette and quartz instrument. The company is located in China Crystal Capital - Donghai City, Jiangsu Prov., China. 70 km far from Lianyungang port, convenient transportation.

Covering an area of 1000 square meters,we now have over 30 employees,an annual sales figure exceeding USD 5.2 million.

With the philosophy of Technology Orientation, Quality First,Integrity and Responsibility,Sustainable Operation, the company dedicates to establish an international enterprise with standard and sustainable operation capability.

Anti Corrosion Fused Quartz Urn 2.2g/Cm3 Chemical Reaction 3

FAQ:

Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the delivery time?
A:Within 15 days after receiving deposit.
Q3. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available
Q4. How to proceed an order in your factory?
A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.

Q5. How do you ship the goods and how long does it take to arrive?
A:DHL, UPS, FedEx or TNT are optional for small order. It usually takes 3-5 days to arrive. Airline and sea shipping are also available.
