Manufacturer Support Custom Fused Thick Quartz Sheet With Hole
Product Details
| Product Name: | Quartz Glass Plate | Material: | SIO2>99.99% |
|---|---|---|---|
| Density: | 2.2g/cm3 | Light Transimittance: | 92% |
| Hardness: | Morse 6.5 | Working Temparature: | 1150℃ |
| Tolerance: | ±0.02mm | Sample: | Customized |
| Highlight |
99.99% SiO2 Fused Quartz Plate,92% Light Transmittance Quartz Glass Plate,1150℃ Working Temperature Fused Silica Plate |
||
Product Description
- Military industrial complex
- Machinery and metallurgy
- Printing and dyeing equipment
- Optical instruments
- High temperature sight glasses
- Fire hole industries
- Electric light source equipment
- Laboratory instruments
- Chemical apparatus
| SiO₂ Content | 99.9% |
| Density | 2.2 g/cm³ |
| Hardness (Moh's Scale) | 6.6 |
| Melting Point | 1732℃ |
| Working Temperature | 1100℃ |
| Maximum Short-term Temperature | 1450℃ |
| Visible Light Transmittance | Above 93% |
| UV Spectral Region Transmittance | 80% |
| Annealing Point | 1180℃ |
| Softening Point | 1630℃ |
| Strain Point | 1100℃ |
| Type | JGS1 (ZS-1) | JGS2 (ZS-2) | JGS3 (HS) |
|---|---|---|---|
| Spectral Characteristics | 180-2500nm | 200-2500nm | 260-3500nm |
| Average Transmittance | 90% | 85% | 85% |
| Bubble Class | 0 | 2 | 2 |
| Birefringence | 1-2 | 1-2 | 1-2 |
| Grain Structure | 1 | 2 | 2 |
| Fringe | 1-2 | 2 | 2 |
| Uniformity | 1-2 | 2 | 2 |
| Fluorescence | 1 | 2 | 2 |
| Radiation Performance | Does not change color | Slight discoloration | Changes color |
- Raw Material
- Single Line Cutting
- Milling and Grinding Machine
- Coarse Grinding
- Fine Grinding
- Polishing
- CNC Machining
- Provide your requirements or application
- We quote according to your requirements or our suggestions
- Customer confirms samples and places deposit for formal order
- We arrange production
